Markets · 07 Verticals
Seven markets. One commitment.
Every product we make lives or dies in the dirt. We engineer for the formation, the rig and the operator — never for the catalog.
01 — Market
Civil Construction
Foundation, micropile and rota-sonic tooling engineered for urban infrastructure, bridges, retaining systems and deep-foundation work.
Construction drilling puts tooling under load in every direction at once — torque, tension, bending and shock — often inside cased holes with zero tolerance for movement above ground. Every string we build for this market is made from high-strength alloy and thread-inspected before it leaves the floor.
Micropiles
Threaded micropile casing manufactured for load-bearing foundation and underpinning applications.
- 5" through 12" outside diameters
- Right-hand and left-hand threaded connections
- Single, double and triple lead thread forms
- Minimum 80 KSI yield material
- Inertia-welded assemblies up to 7 5/8"
Reusable Casings
Recoverable casing built to be pulled, inspected and run again.
- 6" diameter reusable casing
- API Regular threaded connections
- Heat-treated joints for repeat make-and-break cycles
Helical Anchors & Tiebacks
Inertia-welded round shaft and round-corner square shaft anchors for tieback, underpinning and new-construction foundations.
- Round shaft: 2 3/8" through 7 5/8"
- Round-corner square shaft: 1.5", 1.75", 2.0"
- Manufactured in partnership with Helical Anchor Inc.
- Inertia-welded couplings for full-strength joints
Rota-Sonic & Percussive Tooling
- Subs and adaptors for rota-sonic tooling
- Percussive casing and casing bits
02 — Market
Mining
Blast hole, rotary and in-the-hole tooling that holds up to the most abrasive ore bodies on the continent.
Mining production drilling is a volume game — the tooling that wins is the tooling that stays in the hole. We manufacture drill pipe, collars, stabilizers and subs for the three dominant production methods used across surface and underground operations.
DTH / Blast Hole Drilling
A down-the-hole hammer sits directly behind the bit, delivering percussive energy at the rock face for fast, straight production holes in hard formations.
- Blast hole drill pipe
- Stabilizers and reamers
- Subs, adaptors and bushings
Rotary Drilling
High weight-on-bit and rotation drive tricone or rotary bits through soft to medium formations at high penetration rates.
- Rotary drill pipe with heavy-wall upsets
- Drill collars for weight-on-bit
- Integral-blade stabilizers
ITH (In-The-Hole) Tooling
Purpose-built ITH strings for underground production and long-hole drilling, welded and threaded to OEM interchange.
- ITH drill pipe, 1.75" to 7.625" OD
- Drill collars and stabilizers
- Subs, adaptors and bushings
ITH Drill Pipe — manufacturing range
Spec Sheet- Outside diameter
- 1.750" – 7.625"
- Wall thickness
- 0.190" – 1.000"
- Welding
- Submerged arc welded up to 10.750"
- Threads
- Cubex and OEM-interchange thread forms
- Wrench flats
- Machined to rig specification
- Lengths
- Built to customer requirement
Manufactured to interchange with
03 — Market
Geo Environmental
Monitoring well, soil sampling and environmental remediation tooling for geotechnical drillers and consulting firms.
Environmental and geotechnical work demands small-diameter tooling with perfect thread integrity — cross-contamination and stuck strings are not acceptable outcomes on a monitoring program.
J Rods
Cold-drawn high carbon steel rods for soil sampling and monitoring well installation, with 100% thread inspection.
- Lengths: 1 ft, 2 ft, 5 ft and 10 ft
- AWJ, BWJ and NWJ thread connections
- Compatible with Geoprobe, Mobile Drill, Acker and Multi Power
- Cold-drawn high carbon steel
- 100% thread inspection on every joint
Augers & Sampling Tooling
- Soil sampling augersAPI REG and API IF connections
- Subs and adaptors
- Custom crossovers between rod systems
04 — Market
Oil and Gas
Precision components for upstream operations — from shallow workover strings to deep production programs.
We machine and weld to API thread forms and supply the connection hardware that keeps mixed-vintage strings compatible on location.
Drill Collars & Stabilizers
Drill collars provide the weight on bit and stiffness that keeps a hole straight; stabilizers centralize the string and control deviation.
- Drill collars machined from alloy bar stock
- Integral straight-rib stabilizers up to 7 5/8"
- API IF, Regular, FH, FEDP and AOH connections
- Wrench flats machined to rig requirement
- Hard facing applied to rib surfaces
Subs & Adaptors
- Crossover subs, 4140 / 4137 alloy
- Lift subs, bit subs and saver subs
- Custom thread combinations on request
05 — Market
Trenchless Utility
Horizontal directional drilling tooling for fiber, gas, water and electrical utility installation under roads, rivers and rail.
HDD rods live in tension and torsion at the same time, bent around a radius, for thousands of cycles. We build them from grades selected for the pull and the bend — not just the diameter.
HDD Drill Rods
Manufactured 2 3/8" through 6 5/8" for maxi, midi and mini rigs.
- Sizes: 2 3/8", 2 7/8", 3 1/2", 4", 5", 5 1/2", 6 5/8"
- NC or DS connections
- E, X, G and S material grades
- Standard and non-standard wall thickness
- Compatible with Vermeer, Ditch Witch and American Augers
Subs & Adaptors
- Crossovers between NC and DS thread systems
- Starter rods and swivel adaptors
06 — Market
Water Resources
Reliable drill pipe, collars, stabilizers and Kellys for municipal, agricultural and residential water well programs.
Water well contractors run mixed fleets and inherited tooling. We manufacture to the thread form and wrench flat your rig already uses, with upset options selected for the depth and the mud program.
Water Drill Pipe
Built to OEM interchange with internal, external or internal-external upsets.
- Outside diameters 2.375" through 7.625"
- Wall thickness 0.190" through 1.000"
- IU, EU and IEU upset ends
- Friction and submerged arc welded tool joints
Drill Collars, Stabilizers & Kellys
- Drill collars for weight-on-bit control
- Integral straight-rib stabilizers with hard facing
- Kelly bars machined to rig drive
Water Subs & Adaptors
- Machined from 4140 and 4137 alloy
- Crossovers between API, Mayhew and H90 systems
- Bit subs, saver subs and lift subs
Water Drill Pipe — manufacturing range
Spec Sheet- Outside diameter
- 2.375" – 7.625"
- Wall thickness
- 0.190" – 1.000"
- Upset ends
- IU · EU · IEU
- Thread forms
- API IF · API Regular · API FH · FEDP · AOH · Mayhew Regular · Mayhew Jr. · Mayhew FH · H90
- Wrench flats
- T3W / Cyclone · Schramm (old & new) · T4W / DM45 / RD20 · Speed Star · CP650 · Versa · Drill Tech · Foremost · Reich · custom
Manufactured to interchange with
07 — Market
Sonic Drilling & Tooling
High-frequency resonant drilling tooling — casings, subs and adaptors built to DCDMA standards for sonic rigs.
Sonic drilling uses high-frequency resonant energy generated in the drill head and transmitted down the string to the bit face. The vibration fluidizes the soil immediately around the tooling, letting the string advance with far less force and far less disturbance than conventional rotary methods.
Why Sonic
- Continuous, undisturbed core samplesNear-100% sample recovery in unconsolidated ground.
- Dramatically less wasteLittle to no drilling fluid means minimal cuttings to contain and dispose of.
- Faster penetrationAdvance rates of several times conventional rotary in overburden.
- Cleaner, straighter holesCased advance limits cross-contamination between aquifers.
Sonic Casings — W Type
Manufactured to DCDMA standard with a minimum 80 KSI tensile material.
- AW · BW · NW · HW · PW · SW
- Lengths: 2 ft, 5 ft, 10 ft and 20 ft
- Minimum 80 KSI tensile strength
Sonic Casings — WT Type
- AWT · BWT · NWT · HWT · PWT · SWT
- DCDMA standard thread profiles
- Lengths: 2 ft, 5 ft, 10 ft and 20 ft
Rig Compatibility
- Boart Longyear
- Terra Sonic International
- Geoprobe
- Fraste SPA
Sonic casing — manufacturing standard
Spec Sheet- Standard
- DCDMA
- Minimum tensile
- 80 KSI
- W series
- AW · BW · NW · HW · PW · SW
- WT series
- AWT · BWT · NWT · HWT · PWT · SWT
- Lengths
- 2 ft · 5 ft · 10 ft · 20 ft
Your market not listed?
